| Compact, high performance low cost power supply / XPH series

> 제품소개 > DC전원공급기(수입Brand)일반형 DC파워(1CH)AMETEK

프로그램형 DC파워(1CH) (33)

프로그램형 DC파워(2CH~) (11)

1번째 이미지 새창

제품명	Compact, high performance low cost power supply
모델명	XPH series
특 징	•용량: 180~420W
상세사양	• 출력 채널 : 1CH • 전압 : 18–75V • 전류 : 5–20A
브랜드	AMETEK / USA
판매가격	전화문의 : ☎070-4333-8982
배송비	주문시 결제

견적문의 위시리스트

카타로그 메뉴얼

전체목록 ◀◀ 뒤로가기

상품 기본설명

Compact, high performance low cost power supply / XPH series

제품사양

Sorensen XPH Series

Product Overview

The Sorensen XPH Series provides 175 to 420 watts of DC power. The XPH is a compact, high performance low cost power supply suited for benchtop applications.
The Sorensen XPH Series uses combined switch–mode pre–regulation with linear post-regulation to provide performance comparable with an all linear design. The XPH features excellent line and load regulation with low noise and good transient response. The XPH Series is available in a single, dual and triple output for benchtop use.
The Sorensen XPH dual output models have two independent and isolated outputs with its own on–off switch. The outputs can be wired in either series or parallel to provide higher voltage and higher current output. All outputs are instrinsically short circuit proof, and are protected against external voltages and reverse currents. The XPH triple output model has the same features as the dual output model with an additional switchable fixed output of 3.3V and 5V.

Key Features

- Low noise
- Excellent line⁄load regulation
- Coarse and fine voltage controls
- Constant voltage or constant current operation with automatic crossover and mode indication
- Individual ON⁄Off switch per output (not including fixed output)
- Switchable 3.3V⁄5V output on triple output model
- Switchable remote sense (XPH 1810 amd XPH 4210 models)

Specifications
